Advanced DTG Technology
DTG Printing Excellence
Professional direct-to-garment printing using our Kornit Atlas Max Poly machines with XDi technology. Perfect for detailed designs, unlimited colors, and soft-hand finishes. Our advanced fixation system eliminates pretreatment odors and boxes.
Why Choose DTG?
Direct-to-garment printing offers unmatched versatility and quality for complex designs.
Unlimited Colors
Full CMYK + White printing with no color limitations or setup fees.
Photographic Detail
Perfect for complex artwork, gradients, and photographic prints.
Soft Hand Feel
Water-based inks absorb into fabric for a natural, breathable finish.
Outstanding on All Fabrics
Exceptional results on polyester, cotton, and blends with Kornit’s advanced technology.
Technical Details
- Overview
- Process
- Design Guidelines
Fabric Compatibility
| Fabric Type | Compatibility | Washability | Notes |
|---|---|---|---|
| 100% Cotton | Excellent | 50+ washes | Soft hand feel, vibrant colors |
| Cotton/Poly Blends | Excellent | 50+ washes | Great durability and color retention |
| 100% Polyester | Excellent | 50+ washes | Outstanding results with Kornit Atlas Max Poly |
| Tri-blends | Excellent | 50+ washes | Premium soft feel, excellent drape |
Print Specifications
Maximum Print Size (Premium):
14.1″ × 17.7″
Standard Print Size:
12″ × 16″
Resolution:
1200 × 1200 DPI
Ink System:
CMYKNYNP + White
Color Gamut:
Extended sRGB accuracy
Neon Pigments:
Yes (NY + NP)
Ink Type:
Water-based pigment
White Underbase:
Optional (customer choice)
Technology:
XDi (Ink Stacking)
Production Details
Equipment:
Kornit Atlas Max Poly
Technology:
XDi (Fixation on the Fly)
Ink Set:
Atlas Max Poly (215°F cure)
Production Time:
1-3 business days
Fixation Method:
Diluted base + on-the-fly stacking
Pretreatment:
None required
Washability:
50+ washes
XDi Technology
Revolutionary “Fixation on the Fly” System
Our Kornit Atlas Max Poly printers use advanced XDi technology, enabling “Fixation on the Fly” through dedicated print heads. We apply a diluted fixation base to the garment, then print directly on top using wet‑on‑wet technology with fixation stacking capabilities.
XDi allows us to stack multiple layers: Qfix on the white color bridge bonds white ink instantly, while Qfix on the color bridge delivers the same results for colored inks. Poly enhancer (PE) on the color bridge enhances hand feel and durability for retail‑ready finishes.
- No pretreatment odor or visible box
- Superior adhesion with Qfix stacking
- Atlas Max Poly ink cures at 215°F for synthetic fibers
3D Printing Capabilities
The XDi system enables true dimensional printing by layering: White → Qfix → White → Qfix, creating physical texture and depth. Combined with Poly enhancer control, we can achieve precise hand feel and durability tailored to each application.
- 3D layered texture printing (coming soon)
- Lenticular effects (in development)
- Customizable hand feel with Poly enhance
1. Garment Preparation
A light fixation base is applied and wiped clean, preparing the fabric for perfect ink bonding.
2. Advanced Printing
Our XDi system prints your design while applying fixation layers for superior color and durability.
3. Heat Curing
Prints are cured at precisely 215°F, ensuring perfect bonding on all fabric types including synthetics.
DTG vs Other Methods
| Feature | DTG (Kornit XDi) | DTF | Screen Print |
|---|---|---|---|
| Color Gamut | Extended sRGB + Neon Pigments | Full CMYK | Limited by screens |
| Hand Feel | Customizable with Poly enhancer | Raised, sticker‑like feel | Varies by ink |
| Detail Level | Photographic quality | High detail | Limited detail |
| Synthetic Fabrics | Outstanding (215°F cure) | Good adhesion | Limited compatibility |
| Durability | 50+ washes, no cracking | May crack/peel over time | Variable |
| Large Coverage | Excellent, breathable | Heavy feel, not recommended | Limited by screens |
| Setup Cost | None | None | Screen fees |
| Fixation System | XDi (Fixation on the Fly) | Heat application | Sometimes required |
File Requirements
- High resolution PNG files only
- 300 DPI resolution required
- sRGB color space preferred
- True to size dimensions
Design Specifications
- Maximum print size: 14.1″ × 17.7″ (Premium plan)
- Standard print size: 12″ × 16″
- Unlimited colors supported
- White underbase optional
Best Practices
- Avoid designs smaller than 2″ in any dimension
- Use high contrast for text elements
- Consider fabric color in design planning
- Contact support for artwork guidance
White Underbase Options
With White Underbase
- Vibrant colors on dark garments
- Maximum color pop and opacity
- Slightly raised feel (minimal)
- Best for high-contrast designs
Without White Underbase
- Ultra-soft, no-feel finish
- Colors blend naturally
- Ideal for light-colored garments
- Slightly muted on dark fabrics
